Pleomorphic adenoma of the maxillary sinus with orbital extension presenting with exophthalmos: a case report

Spyridon Lygeros1^, Foteini Tsapardoni2^, Stylianos Mastronikolis2^, Anna-Maria Axioti1, Ioanna-Maria Grypari3^, Gerasimos Danielides1, Stephanos Naxakis1^

1Department of Otorhinolaryngology, University Hospital of Patras, Patras, Greece; 2Department of Ophthalmology, University Hospital of Patras, Patras, Greece; 3Department of Pathology, School of Medicine, University of Patras, Patras, Greece

^ORCID: Spyridon Lygeros, 0000-0003-0642-6697; Foteini Tsapardoni, 0000-0003-0926-6393; Stylianos Mastronikolis, 0000-0003-4815-5880; Ioanna-Maria Grypari, 0000-0001-6042-6554; Stephanos Naxakis, 0000-0003-2134-4323.

Correspondence to: Spyridon Lygeros, MD, PhD. Clinical and Academic Fellow in Otorhinolaryngology, University Hospital of Patras, Rion Patras, GR 26504, Greece. Email: spyroslygeros@gmail.com.

Abstract: We report a case of pleomorphic adenoma (PA) of the maxillary sinus, an unusual and rare location of this frequent benign neoplasm originating from salivary glands and accounting for 70% of all salivary gland tumors, presenting with compressive phenomena from the orbit and the challenges in its differential diagnosis and management. A 66-year-old male presented with progressively worsening exophthalmos over the past 4 months and symptoms of nasal obstruction on the left side for the past year. Clinical evaluation and imaging studies revealed complete occupation of the left maxillary sinus by a mass with soft tissue characteristics, extending to the homonymous nasal cavity and orbit. Functional endoscopic sinus surgery (FESS) was performed. The surgical plan included septoplasty and medial maxillectomy and complete resection of the tumor with clear margins. The histopathology report was consistent with a PA of the maxillary sinus. PA of the maxillary sinus is an extremely rare disease entity. Orbital involvement due to extension of an undiagnosed PA as described in this case is very uncommon. Thorough investigation is required in cases of unilateral nasal obstruction. Complete surgical excision and close long-term follow-up are required due to the probability of tumor recurrence and potential malignant transformation.

Keywords: Pleomorphic adenoma (PA); maxillary sinus; exophthalmos; functional endoscopic sinus surgery (FESS); case report


Received: 08 May 2021; Accepted: 06 August 2021; Published: 25 October 2021.

doi: 10.21037/acr-21-31


Introduction

Pleomorphic adenomas (PA) of the nasal area and paranasal sinuses are extremely rare and slowly progressive benign tumors. PAs are mostly encountered in the major salivary glands, typically in the parotid, comprising 80% of all benign parotid neoplasms, and less frequently in the minor salivary glands of the soft palate, nasal cavity and paranasal sinuses, as well as the nasopharynx, lacrimal glands, trachea and larynx (1). Herein, we report a rare case of PA located in the maxillary sinus, with an unusual facial presentation, accentuating that the unusual site of the mass could preclude its timely diagnosis and be associated with complications. The diagnostic and therapeutic approach selected for our patient are discussed, in accordance with the CARE reporting checklist (available at https://dx.doi.org/10.21037/acr-21-31).


Case presentation

A 66-year-old Caucasian male presented to the Emergency ENT Department of the University Hospital of Patras, complaining of progressively worsening symptoms of nasal obstruction on the left side. The patient had been experiencing nasal congestion and blockage for the past year, while he reported deterioration in nasal breathing and excessive snoring during the last 6 months prior to his presentation. A slowly developing proptosis of the left eye was also observed by the patient over the past 4 months, without any other ocular symptoms. He reported no rhinorrhea, episodes of epistaxis or allergy history. His past medical history included head injury due to a motor vehicle accident 20 years ago, while the remainder of his medical history was otherwise unremarkable.

The patient was admitted for further investigation in the ENT department. On clinical examination, there was marked proptosis of the left globe, while anterior rhinoscopy and fiberoptic nasendoscopy revealed a mass located in the left nasal cavity blocking the left nostril. Furthermore, a left deviation of the nasal septum and oedema of the right inferior nasal turbinate were noticed. Intraoral and ear examination was normal. Ophthalmic evaluation showed subtle restriction in the downward gaze with no other defects in ocular motility, while visual acuity and fundus examination were normal.

High resolution computed tomography (CT) scan of the paranasal sinuses demonstrated complete occupation of the left maxillary sinus by soft tissue elements with extension to the adjacent structures. CT findings included erosion of the medial wall of the maxillary sinus and extension of the mass into the nasal cavity up to the nasal septum causing obstruction of the airway. Furthermore, extension of the mass to the orbital floor coming in contact with the left globe resulted in pressure to the left periorbital area, with mild proptosis and possibly erosion of the left inferior rectus muscle (Figure 1). Based on the features described in CT, a mucocele was set high in the differential diagnosis.

Figure 1 Axial (A,B) and sagittal (C) CT images revealing a mass occupying the left maxillary sinus with erosion of its medial wall and extension into the nasal cavity up to the nasal septum. Extension through the orbital floor was associated with proptosis and possibly erosion of the left inferior rectus. CT, computed tomography.

For further evaluation of the soft tissue component of the mass, magnetic resonance imaging (MRI) was performed. MRI confirmed the complete occupation of the left maxillary antrum by material characterized by heterogenicity and intermediate signal intensity in T1-weighted MR images and high signal intensity in T2-weighted MR images (Figure 2A). After intravenous injection of paramagnetic contrast agent, signal intensity increase (enhancement) of the mass was observed (Figure 2B). Based on the unilateral nature of the disease and its radiographic features, the differential diagnosis included an inverted papilloma, lymphoma, squamous cell carcinoma, adenomatous tumors such as the cystic adenocarcinoma, or another neoplasm arising from the maxillary sinus.

Figure 2 Magnetic resonance images. (A) Axial T1-weighted fat-suppressed image demonstrating a soft tissue mass of intermediate signal intensity with internal heterogenicity occupying the left maxillary sinus with extension into the nasal cavity. (B) Coronal T2-weighted image; the mass exhibits high signal intensity. (C) Post-contrast coronal T1 image showing enhancement of the mass.

Due to the extent and location of the lesion, accessing the mass endoscopically in order to perform a preoperative biopsy was not possible. Therefore, for both diagnostic and therapeutic purposes, functional endoscopic sinus surgery (FESS) under general anesthesia with the surgical plan of an extended biopsy was considered the treatment of choice. Surgery included endoscopic septoplasty for the deviated nasal septum. Following that, a medial maxillectomy was performed. Intraoperatively, a soft tissue tumor, attached to the lateral wall of the maxillary antrum expanding to the orbit with attachment to the periorbita was observed (Figure 3). En bloc resection of the mass was achieved with clear resection/surgical margins after thorough dissection and separation from the surrounding tissues. The tissue removed was sent for pathology examination.

Figure 3 Intraoperative endoscopic image demonstrating a whitish soft tissue mass attached to the lateral wall of the maxillary sinus and expanding into the orbit in contact with the periorbita.

Histopathology report revealed a biphasic tumor, developing under the pseudostratified columnar epithelium, composing of both epithelial and stromal component with moderate cellularity. The two elements were closely mixed. The epithelial cells were forming tubules, sheets with ductular structures and cords, while the stromal component had myxoid and focally cartilaginous differentiation. Immunohistochemical stains were performed in order to confirm the biphasic elements (Figure 4A-4D). Epithelial cells were positive for p63 and negative for S100 while the stromal cells were positive for S100 and negative for p63. Based on the morphology and the immunohistochemical stains, the diagnosis was mixed tumor/PA of the maxillary sinus surrounded by respiratory mucosa without any evidence of malignancy. Resection margins were clear. The post-operative period was uneventful. Left exophthalmos resolved after surgery. Short- and long-term prognosis following complete tumor excision was considered excellent. However, due to the small risk of recurrence the patient remained under close follow up every 3 months during the first year, with imaging and repeated nasal endoscopic examination without any signs of recurrence.

Figure 4 Histopathology images. (A) A myxoid neoplasm with moderate cellularity was observed beneath the pseudostratified respiratory mucosa. (Eosin & hematoxylin stain, magnification 4×). (B,C) Higher magnification (10×) highlighted a biphasic neoplasm, composed of both epithelial and stromal component. The epithelial component formed cord-like tubular structures and sheets of epithelial cells with scattered ductules. The stromal component was mainly myxoid or exhibits cartilaginous differentiation. (D) The neoplasm developed above the bone trabeculae without invading or distorting it.

All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and national research committees and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient for publication of this case report and accompanying images. A copy of the written consent is available for review by the editorial office of this journal.


Discussion

PA is the most common benign salivary gland tumor, accounting for 45–74% of all salivary gland neoplasms. It typically arises from major salivary glands, namely the parotid in 65% of the cases (2). PAs constitute mixed tumors consisting of epithelial, myoepithelial and stromal component with well demarcated margins separated from healthy tissue by a fibrous capsule. Epithelial differentiation as well as the diversity of the stromal patterns are responsible for its high pleomorphism (3). More specifically, the epithelium can form sheets or duct-like structures. Myoepithelial cells may be arranged either in a reticular pattern or sheets of spindle shaped cells, while their stromal component can be myxoid, fibrous/hyalinized or chondroid.

About 10% of all PAs originate from minor salivary glands distributed throughout the upper aerodigestive tract. PAs of the upper respiratory airway are rarely described and usually affect the nasal cavity with involvement of the septum in 82.5–90% of the reported cases, followed by the maxillary sinus and nasopharynx (4,5). They usually present between 30 and 60 years of age with a slight predilection for women. As opposed to major salivary glands’ PAs which are characterized by relatively low myoepithelial cellularity, the ones of the aerodigestive tract exhibit high cellularity and absence of stromal component, simulating more aggressive epithelial neoplasms.

The origin of sino-nasal PAs remains debatable. A theory proposed from Matthew et al. suggests that a misplaced embryonic epithelial cell in the mucosa of nasal septum could be the cause of a PA (6). Another theory supports that these PAs may originate from remnants of the vomeronasal organ from early fetal life (7).

Although PAs are benign, local recurrence is a potential risk, while malignant transformation into carcinoma ex-PA is encountered in about 6% of all PA cases (8). Following resection, the recurrence rates reported vary from 0 to 8%, while multiple recurrences are associated with malignant transformation (9). The presence of a highly myxoid stroma and an irregular or invaded capsule with multinodularity increase the risk of local recurrence. Metastasis can also occur particularly in cases where enucleation or incomplete excision is performed.

Clinical presentation is with nasal obstruction (in 71% of cases), epistaxis (56%), epiphora, rhinorrhea. Occasionally, an external deformity of the nose may be observed depending on the bulk of the tumor. Imaging with both CT and MRI is of paramount importance when clinical suspicion of a neoplasm is present.

Diagnostically, an extended biopsy with debulking through an endonasal, endoscopic approach when easily accessible, may be optimum for establishing a correct diagnosis especially in cases of large tumors, all the while providing patient relief from symptoms of obstruction. Wide surgical excision is the mainstay of treatment aiming for clear clinical margins of at least one centimeter to avoid possible recurrence. Postoperative radiotherapy has been suggested by some authors in the presence of residual disease (4).

As far as the PAs of the maxillary sinus are concerned, there are few case reports in literature. A review of 40 cases of intranasal PAs from Compagno and Wong, reported 23 cases in females and 17 in males, 62% of which originated in the nasal septum. No cases primarily involving the maxillary sinus were found. However, three cases showed extension of the PA from the nasal septum to the maxillary sinus (10). In a review of 2,807 cases of salivary gland tumors, Spiro reported no tumors located in the maxillary and ethmoidal sinuses (11). Similarly, in a retrospective analysis of benign sinonasal tumors managed with FESS, 2 out of 105 cases were PAs, indicating the rarity of the tumor in the specific location (12).

Martis and Karakasis were the first to report a case of maxillary sinus PA presenting with cheek swelling in 1971 (13). Cases presenting with similar symptoms have been described by Leunig involving an elderly patient complaining of nasal obstruction and occasional epistaxis (14) and Berenholz et al. (15). Another case showing repeated recurrence and bone formation was reported by Lee et al. (5). All of the abovementioned cases were managed with open surgery. In 2002, Facon et al. described a case arising from the medial wall of the maxillary antrum treated via an endoscopic approach (16). Ray et al. reported a case of a large PA of the maxillary antrum with extensive ossification presenting with maxillary swelling mistakenly attributed to odontogenic origin (17). An intra-sinus PA with comparable clinical presentation in a 17-year-old was reported by Razafindrakoto et al. (18). Lately, a retrospective analysis of 17 patient’s data also included one case of PA originating from the maxillary sinus (19). According to a case series presentation based on retrospective review by Kuan et al. including 39 patients endoscopic resection was employed in 66% of cases, which achieved oncologic control in more than 80% of cases at a mean follow-up of 2 years (20). Although no cases of PA were reported, one case of carcinoma ex-PA originating from the maxillary sinus was found, as PAs are capable of undergoing malignant transformation.

We report an atypical case of unilateral PA originating from the maxillary sinus, presenting with proptosis due to erosion of the orbital floor and invasion of the orbit by the tumor. Taking into consideration the radiographic studies, we proceeded surgically with an extended surgical biopsy, which set the diagnosis of PA. Endoscopic sinus surgery ensured local but adequate tumor resection with no recurrence at 1 year follow up in our patient. However, a limitation that applies in our case is the lack of long-term follow-up and empirical surveillance data availability, as PA recurrence tends to occur later than 2 years post-resection.

To conclude, except for the rarity of the disease, this case highlights that high clinical suspicion is required in cases of unilateral nasal obstruction, particularly when accompanied by orbital features. Given the nature and chronicity of symptoms, early detection of such pathology necessitates proper investigation with endoscopy and imaging. In the absence of clinically evident characteristic findings of sino-nasal PAs, we emphasize the role of imaging with CT and MRI in evaluating unilateral invasive lesions of the area. Additionally, accurate tumor sampling is vital for prompt diagnosis and management. It is worth mentioning that the majority of patients may be eligible for endoscopic surgical excision, providing a satisfactory treatment outcome without radical procedures. Long-term follow-up is necessary for monitoring possible recurrence of the tumor.
