Machine-vision image guided C4-C5 unilateral cervical pedicle screw insertion: case report and review of literature

Tiffany Yeretsian1, Carolyn Lai2, Daipayan Guha2, Joel Ramjist3, Victor X. D. Yang2,3

1School of Medicine, The Royal College of Surgeons in Ireland, Dublin, Ireland; 2Department of Surgery, Division of Neurosurgery, University of Toronto, Toronto, Canada; 3Deparment of Electrical, Computer, and Biomedical Engineering, Ryerson University, Toronto, Canada

Correspondence to: Victor X. D. Yang, MD, PhD, FRCSC, PEng. Department of Surgery, Division of Neurosurgery, University of Toronto, Toronto, Canada. Email: victor.yang@utoronto.ca.

Abstract: Computer-assistance for pedicle screw insertion is becoming increasingly common. As in the case presented below, image guided neuronavigation can be used to improve the accuracy and safety of subaxial cervical pedicle screw placement, given their increased difficulty of cannulation relative to the larger pedicles in the thoracolumbar spine. A 49-year-old man presented with a traumatic sagittal split fracture of C4 (AO Classification type A4) and a left lateral mass fracture of C5 (AO Classification type F1) with anterior depression and 50% height loss. MRI revealed evidence of strain of the interspinous/supraspinous ligaments (AO Classification type B2), as well as fluid within the left C4-C5 facet joint. Along with these fractures, the young patient had Klippel-Feil syndrome with autofusion of the C2-3 posterior elements, and a left vertebral artery dissection. He had neck pain but was otherwise neurologically intact. The patient underwent machine-vision image guided C4-C5 unilateral pedicle screw insertion connected by a fixation rod for stabilization and bone graft to augment the instrumented fusion with good outcome. The use of machine vision spinal navigation was able to provide accurate and precise placement of pedicle screws without significantly increasing surgical time. This method has the potential to allow for the safe and accurate insertion of cervical pedicle screws and to reduce the rate of pedicle breach which could avoid significant neurovascular injury.

Keywords: Klippel-Feil syndrome; unilateral pedicle screw fixation; computer-assisted; subaxial cervical spine; case report

Received: 08 September 2021; Accepted: 14 October 2021; Published: 25 January 2022.

doi: 10.21037/acr-21-62

Introduction

Roy-Camille performed the first posterior cervical screw fixation in 1979. Since then, middle and lower cervical spine fixation methods have evolved (1). Cervical spine fixation by pedicle screws is an established technique at C2 and C7, this technique is more challenging in the C3 to C6 region as the pedicles are frequently smaller in size as compared to C2 and C7 (2).

Over the past decade, spinal surgery has significantly evolved as a result of increased need for spinal fusion procedures. The number of spinal fusion procedures have risen in recent decades, and is expected to continue to steadily rise in the coming decades as the population ages (3). Computer-assistance was introduced to improve accuracy and safety of operative procedures; however, successful implementation of posterior cervical instrumentation remains a challenge. A posterior approach is most common, with lateral mass screws inserted and fixated using rods (4). Since pedicles in the cervical spine are smaller, there are risks such as injury to the spinal cord and nerve roots, or injury to the vertebral artery by placing pedicle screws in this area. Also due to the very lateral to medial angulation of the cervical pedicle trajectory, cervical pedicles are rarely performed because of the significantly wide and morbid exposure required in order to insert the screws in this area. As such, cervical pedicle screws at the C3-6 levels are less commonly performed.

Computer-assisted navigation aims to improve the accuracy of screw placements at all spinal levels. While it has been reported that 12–40% of cervical pedicle screws inserted using freehand techniques have breached outside of the intended trajectory, the use of neuronavigation hopes to reduce the breach rate to under 10%, which should in turn lower the risk of acute neurovascular injury and longer-term mechanical construct failure (5). The operation discussed in this case report used machine vision and optical topographical navigation (7D Surgical Inc., Toronto, Canada) to co-register bony anatomy with pre-existing imaging without using any radiation. Registration is rapid and can be repeated within seconds if the patient tracker is displaced. Unique to this spinal navigation system, it can capture >480,000 data points in a 40×30 cm area with a 4–6 points/mm2 resolution (6).

We present the following article in accordance with the CARE reporting checklist (available at https://dx.doi.org/10.21037/acr-21-62) (7).

Case presentation

A 49-year-old man fell down a flight of stairs with a subsequent brief loss of consciousness. Thereafter he was able to stand and mobilize independently. Due to persistent neck pain, he went to see his family physician and plain cervical radiographs were performed, demonstrating fractures resulting in subsequent admission to hospital for investigation.

CT imaging demonstrated Klippel-Feil syndrome of C2-3, a sagittal split fracture of C4 (AO Classification type A4), and a left lateral mass fracture of C5 (AO Classification type F1) with anterior depression and 50% height loss. MRI showed STIR signal in the interspinous and supraspinous ligaments (AO Classification type B2). Paravertebral edema related to the sagittal oriented fracture of the C5 spinous process was discovered and there was fluid within the left C4-C5 facet. The fracture on C5 involved the right lamina and the spinous process. There was a nondisplaced fracture of the left C5 superior articular process. There was no dislocation or subluxation. The patient also had a left vertebral artery dissection for which consideration was taken prior to the surgery (Figure 1). Given the unstable nature of his cervical injury, the patient consented for posterior short segment C4-C5 instrumented fusion which was deemed the most appropriate treatment to provide stability while preserving range of motion, taking into consideration his Klippel-Feil syndrome.

Figure 1 Pre-operative imaging showing C5 fracture. (A) Pre-operative X-ray showing C2-3 Klippel-Feil syndrome and 50% height loss of C5 with anterior depression. (B) Pre-operative CT showing a sagittal split fracture of C4. (C) Pre-operative CT showing a left lateral mass fracture of C5.

Using image guided navigation, the level and angle of the spinal fracture were registered with excellent accuracy. Registration was done in a segmental fashion to ensure accuracy by eliminating inter-segmental mobility. The complete details of navigation registration technique and workflow are covered in a prior publication (5). Briefly, the 7D Surgical navigation head unit was brought above the surgical field following standard posterior midline exposure of the cervical spine. Structured light imaging was used to generate a 3D point cloud of the exposed osseous anatomy, with high-speed automatic registration to the thin-slice pre-operative CT scan. Image guided instrumentation was then performed with optically tracked tools (5).

Using a navigated drill guide, the C4 and C5 pedicle screws were cannulated on the left side (Figure 2) through a separate paramedian percutaneous stab incision. The cervical instrumentation system (Zimmer Biomet Spine Inc., Westminster, CA, USA) was used to place a 4.5×24 mm pedicle screw at C4 and a 4.5×26 mm pedicle screw at C5, both on the left side. A 3.5 mm rod was placed to connect the two pedicle screws. Since these screws cannulated the pedicle as well as the anterior column for both levels, a conscious decision was made to preserve the right side as it remained uninjured.

Figure 2 Intraoperative images showing navigated pedicle preparation over separate stab incision. Images of the operative field demonstrating planning of a stab incision (A) and percutaneous pedicle screw placement (B) using navigation guidance. Corresponding intra-operative 7D Surgical neuronavigation views of pedicle targeting at C4 (C) and C5 (D).

After decortication, morselized bone graft from spinous processes were placed as autologous bone graft through a small midline incision for bone graft application for fusion. The patient tolerated the procedure well, had an unremarkable post-operative course and was discharged the following day. CT showed good placement of the left pedicle screws at C4 and C5 (Figure 3). Longer-term follow-up is needed to determine if fusion has occurred.

Figure 3 Immediate post-operative CT scan of C4 (A) and C5 (B) vertebra showing the (C) unilateral placement of the rod.

All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and national research committee and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient for publication of this case report and accompanying images. A copy of the written consent is available for review by the editorial office of this journal.

Discussion

Cervical pedicle screws are an alternative option for posterior cervical fixation, with increased pullout and rotational strength relative to standard lateral mass instrumentation (8,9). The use of subaxial cervical pedicle screws has been limited by the relatively low margin for error afforded by the smaller pedicle diameters relative to the thoracolumbar spine, with increased potential for catastrophic neurologic or vascular injury with inaccurate placement. Multiple techniques for improving the accuracy of subaxial pedicle screw placement have been described, including intra-operative fluoroscopy, 3D-printed patient-specific drill guides, and computer-assisted navigation (4,10). Traditional navigation requires additional intra-operative radiation or significant time cost with intra-operative imaging devices. We show here a technique for safe and efficient insertion of subaxial cervical pedicle screws with machine-vision image-guidance.

In the case of this young patient, conventional lateral mass fixation would have necessitated a multilevel construct extending above and below the injured levels, significantly diminishing range of motion. With pedicle screw based fusion technique, given that the pedicles were intact, a much shorter construct from C4 to C5 provided adequate stabilization and sufficient mechanical strength since the longer pedicle screws provide both posterior and anterior column support. Pedicle screws have been found to have significantly improved pullout strength relative to lateral mass screws in both flexion, extension and axial rotation (8,9).

A unilateral left sided approach avoided the risk of injuring the only remaining intact vertebral artery for this patient. Overall, this approach provided a balanced trade-off between mechanical strength for fusion, motion preservation in the context of Klippel-Feil syndrome, and risk of arterial injury. The use of machine-vision image-guided surgery allowed accurate placement of C4 and C5 pedicle screws through a separate paramedian stab incision, with a small midline incision for bone graft application for fusion.

The machine vision image guidance system (7D Surgical) is substantially more time efficient than an intraoperative CT-based navigation system. As shown in Table 1, the 7D navigation system took under 2 min to register the points of both vertebrae. Comparatively, an intraoperative CT-based navigation system could take between 5–10 min for each vertebra if segmental registrations of each spinal levels were attempted (6).

Table 1

Showing registration workflow time, registration processing time, number of points used for registration and calculated registration error for C4 and C5 vertebra

Intraoperative registration C4 C5
Registration workflow time 64 s 48 s
Registration processing time 1.73 s 4.82 s
Number of points used for registration 710 722
Calculated registration error, mm 0.3259 0.3111

Immediate post-operative CT scans were taken to ensure accurate placement of the pedicle screws in the C4 and C5 vertebrae (Figure 3). At the three-month follow-up, imaging results revealed that good hardware placement and alignment were maintained, and the fracture was healing well (Figure 4).

Figure 4 Three-month post-operative X-ray showing good alignment and fixation of the screws in the vertebrae.

Over the past few decades, computer-assisted navigation for spinal indications have become more widespread, with computer-assisted navigation procedures demonstrating greater accuracy and precision. The benefits of navigation in spine surgery have been shown in multiple research studies, as seen in Table 2. In a study by Rajasekaran et al. (11), which compared non-navigated versus navigated screw insertion in the thoracic spine, the non-navigation group had 54 (23%) pedicle breaches compared to only 5 (2%) in the C-arm based navigation group. Another study by Barsa et al. (12) found that of 295 screws inserted throughout C0 to S1 using intraoperative CT-based spinal navigation, only 4 (1.3%) pedicle screws were incorrectly inserted. Lastly, Shin et al. (13) compared the perforation risk for computer-navigated versus freehand insertion in all spinal regions and found the risk of pedicle perforation in navigated screw insertion to be 6% whereas non-navigated insertion was 15%.

Table 2

A summary of findings included in this review

Authors No. of patients Primary objective Principal findings
Navigation improves accuracy at all levels of the spine
   Rajasekaran et al., 2007 (11) 27 To compare the accuracy of pedicle screw fixation in thoracic spine deformities correction surgery between a non-navigation group and a group where C-arm based navigation was used C-arm navigation was able to increase accuracy while reducing total time of surgery
   Barsa et al., 2014 (12) 50 To investigate the accuracy, intraoperative complications and accessibility of CT-based computer-assisted spinal navigation CT-based computer-assisted spinal navigation has higher accuracy in screw insertion, therefore it has the possibility of lowering surgical complications as well as lowering the total time of surgery
   Shin et al., 2012 (13) 8,539 screws To compare the accuracy of computer-navigated to non-navigated techniques in the insertion of pedicle screws in published literature For all spinal regions, navigated screw insertion had a significantly lower risk of pedicle perforation as compared with non-navigated insertion
Navigation improves accuracy specifically for subaxial cervical instrumentation
   Kotani et al., 2003 (14) 17 To compare accuracy, surgical outcomes and complication rates in a group that used computer assistance to insert a screw and a group that used manual insertion to insert a screw Cervical pedicle screw insertion with computer-assistance was safer and more accurate when compared to the manual technique of screw insertion
   Ishikawa et al., 2011 (15) 21 To evaluate the use of an intraoperative, full-rotation, 3D image (O-arm)-based navigation system in terms of reliability and accuracy when placing a cervical pedicle screw The use of the O-arm offered high-quality navigation with high-resolution images helping with the accurate and safe insertion of cervical pedicle screws
   Bredow et al., 2015 (16) 64 To examine 3D fluoroscopy navigation in its accuracy of pedicle screw insertion 3D-fluoroscopy-based navigation systems allow for the accurate insertion of axial and subaxial screws
Navigation can reduce operating room personnel radiation
   Bilhar et al., 2018 (17) 8 To determine whether fluoroscopic guidance or computer-assisted navigation methods is more accurate in the insertion of pedicle screws into the thoracic spine The accuracy of both techniques were shown to be equal. Computer-assisted navigation had the added benefit of not using radiation which improves safety of operating room personnel
   Smith et al., 2008 (18) 4 To compare the risk of radiation exposure to the operative surgeon when inserting pedicle screw-rod constructs using C-arm fluoroscopy versus computer-assisted image guidance When the operative surgeon used computer-assisted image guidance there was a significantly lower exposure to ionizing radiation to the torso as opposed to when the C-arm was used for the same procedure
Navigation can be cost efficient
   Dea et al., 2016 (19) 502 To determine whether computer-assisted surgery has economic advantages as compared to fluoroscopy Computer-assisted surgery was shown to reduce the need for reoperations as compared with the group which used fluoroscopy. This means that it has the potential to be cost-efficient
   Al-Khouja et al., 2015 (20) 13 studies To analyse whether there are any economic benefits to using image-guided surgery and navigation in spine surgery Despite some studies showing lower costs associated with intra-operative imaging, there is still a need for further investigation into the added economic benefits of using these techniques

Navigation has also shown to specifically improve the accuracy for subaxial cervical instrumentation. A controlled trial by Kotani et al. (14) compared patients undergoing computer-assisted navigation cervical pedicle screw insertion with a control group which underwent manual cervical pedicle screw insertion. Compared to the control group, the computer-assisted navigation group had a lower rate of pedicle wall perforation, and screw trajectory in the horizontal plane was considerably closer to the anatomical pedicle axis. Another study by Ishikawa et al. (15) found that of 108 cervical pedicle screws placed using an intraoperative, full-rotation, 3D image (O-arm)-based navigation system, there were minor pedicle violations in 8.3% of cases and major pedicle violations in 2.8% of cases. They concluded that 3D image-based navigation may be more accurate and reliable if used with other techniques. Lastly, a study by Bredow et al. (16), found that in 64 patients undergoing screw implantation using 3D-fluoroscopy-based navigation, 93.9% of the screws implanted at C1 or C2 and 78.51% of the screws implanted at C3-7 showed placement accuracy grade 2 or better according to the modified Gertzbein and Robbins classification.

Another benefit of using image-guided navigation is that it can reduce operating room personnel radiation exposure. A study by Bilhar et al. (17) found that the accuracy of pedicle screw insertion into the thoracic spine using fluoroscopic guidance relative to computer-assisted navigation techniques was equal and consistent; however, the advantage of using the computer-assisted navigation technique versus fluoroscopic guidance is that the surgical team is not exposed to radiation. Smith et al. (18) found that when performing lumbar pedicle screw placement, the mean radiation to the torso of the surgeon was 4.33±2.66 millirem when using standard fluoroscopy compared to 0.33±0.82 millirem when using computer-assisted image-guidance. The higher radiation by using standard fluoroscopy came with no increased accuracy as both techniques had equal accuracy of screw placement.

Several barriers exist before navigation can be implemented in spinal surgery. A major barrier is the cost of the navigation systems. Despite the high initial costs of navigation, evidence exists that navigation can have long-term cost-efficiency. A study by Dea et al. (19) found a 95.2% accuracy rate for a treatment group that used computer assistance and an 86.9% accuracy for a control group that used conventional fluoroscopy. Within one year following surgery, two patients from the treatment group underwent revision surgery whereas 15 patients from the control group underwent revision surgery. The high cost of computer-assisted technologies can be counterbalanced by the overall reduction in revision surgeries necessary. A literature review by Al-Khouja et al. (20) found that the cost for revision surgery was between $17,650 and $39,643. This cost could be reduced if the need for revision surgery diminishes with the use of image-guidance systems. While there is promising data, an insufficient amount of studies reporting on the economics of spinal navigation currently exists to accurately conclude on its cost-effectiveness in clinical practice.

Conclusions

The benefits of using computer-assisted navigation while inserting pedicle screws into the spine has been widely reported. Not only does computer-assisted navigation reduce screw misplacement rates, it has also been proven to improve accuracy and precision, and also contributes to a significant reduction in revision surgeries following spinal procedures. As demonstrated through this case report, the use of machine vision spinal navigation was able to provide accurate and precise placement of pedicle screws without significantly increasing surgical time. In the case of cervical pedicle screws, precision in screw insertion is of particular importance since cervical pedicles are small, and pedicle screws are an alternative option for fixation when lateral masses are fractured. Cervical pedicle screws can lead to a shorter segment fusion as demonstrated in this case report, which unlike lateral mass screws, also provides fixation to support the anterior, middle and posterior columns of the spine. Computer-assisted navigation has the potential to allow for the safe and accurate insertion of cervical pedicle screws and to reduce the rate of pedicle breach which could avoid significant neurovascular injury.
